HB2 SDS Plus Hammer Drill Bit

The kwb hammer drill bits have a high-temperature brazed, impact-resistant carbide plate that impress with good drilling performance in hard materials such as concrete and stone. The milled dual helix is responsible for good drill dust transport. The 2-cutters with SDS Plus mounting shank for common hammer drills are made of high-quality tool steel, which ensures a long service life. The SB clip protects the hammer drills against theft.

Art.-Nr.	Ø mm	e	Working Length

Art.-Nr.	Ø mm	e	Working Length
265004	4	110	50
265005	5	110	50
265006	6	110	50
265007	7	110	50
265008	8	110	50
265009	9	110	50
265010	10	110	50
265055	5,5	110	50
265105	5	160	100
265106	6	160	100
265107	7	160	100
265108	8	160	100
265109	9	160	100
265110	10	160	100
265112	12	160	100
265155	5,5	160	100
265165	6,5	160	100
265206	6	210	150
265208	8	210	150
265209	9	210	150
265210	10	210	150
265212	12	210	150
265214	14	210	150
265216	16	210	150
265306	6	260	200
265308	8	260	200
265310	10	260	200
265312	12	260	200
265314	14	260	200
265365	6,5	260	200
265408	8	460	400
265410	10	460	400
265412	12	460	400
265414	14	460	400
265416	16	460	400
265418	18	460	400
265420	20	460	400
265422	22	460	400
265424	24	460	400
265425	25	460	400
265428	28	460	400
265430	30	460	400
265491	5 / 6 / 8 / 10	110	41
265492	5 / 6 / 8 / 10	110 / 160	41 / 91
265493	5 / 6 / 8 / 6 / 8 / 10 / 12	110 / 160	41 / 91
265494	5 / 6 / 8 / 10	160	91
265698	12 / 16 / 24	1000	940
265699	10 / 12 / 16 / 22 / 25	600	540
